2L Series High-Pressure Steam Valve Piston Type (NC) – Teflon Seal

1/2″ to 2″ (DN15-DN50) G/NPT Threaded Solenoid Valve. Specifically designed for High-Pressure Steam and Thermal Fluids. Normally Closed (NC).

  • High Pressure Rating: Reliable operation up to 1.6 MPa (16 Bar / 232 PSI).

  • Superior Heat Resistance: Handles fluid temperatures from -5°C to 180°C.

  • Rugged Construction: Pilot-operated piston design available in Forged Brass or Stainless Steel (SS304).

  • Industrial Insulation: Equipped with Class H high-temperature coils (IP54).

Add to quote

The 2L Series is a high-performance, pilot-operated piston solenoid valve engineered for demanding industrial thermal applications. Unlike standard domestic valves, the 2L series is built to withstand rigorous pressure fluctuations, making it the premier choice for steam control, heat exchangers, and industrial boiler systems.

Available in both robust Forged Brass and corrosion-resistant Stainless Steel (SS304), this series utilizes high-purity PTFE (Teflon) seals to ensure bubble-tight shutoff even under extreme temperatures. The sophisticated pilot-operated mechanism allows for efficient handling of high-flow rates with minimal power consumption, ensuring long-term reliability in 24/7 industrial environments.

Technical Specifications

    • Body Material: Forged Brass / Stainless Steel 304

    • Seal Material: PTFE (Teflon)

    • Operation: Pilot-Operated Piston (Normally Closed)

    • Pressure Range: 0.05 – 1.6 MPa (0.5 – 16 Bar)

    • Temperature Range: -5°C to 180°C (23°F to 356°F)

    • Interface: G Thread/ NPT Thread

    • Voltage Options: AC 220V, 110V / DC 24V, 12V

    • Protection Class: IP54 / IP65

    • Insulation: Class H

    • Certification: CE

Voltage

AC220V / AC230V, AC110V / AC120V, DC24V
Port Size

1/2″, 3/4″, 1″, 1-1/4″, 1-1/2″, 2″
Body Material

Brass, SS304
