Grinding Wheels, Diamond CBN Wheels & Tools, PCD PCBN PDC CVD MCD ND Tool Cutter, Abrasive Tools, Metalworking Woodworking Tools
Showing all 19 results
Resin bond and hybrid bond superabrasive grinding wheels for 5-axis CNC tool grinding machines.
Available in diamond and CBN abrasive, covering fluting, gashing, OD grinding, and relief & point grinding.
Compatible with ANCA, Walter, Rollomatic, Ewag, and other universal CNC cutter grinders.
The VD-1A1 slotting wheel is a 1A1 straight-profile diamond grinding wheel engineered for precision slotting and grooving of tungsten carbide saw blades, hard alloy cutting tools, and ceramic workpieces.
Available in vitrified bond for controlled stock removal and clean slot geometry, and metal bond (bronze) for heavy-duty, high-frequency slotting applications requiring maximum wear resistance and profile retention.
Both variants feature a full-face abrasive layer for consistent slot width across the wheel life.
The ED-11A2 is an 11A2 bowl-profile electroplated diamond grinding wheel designed for gashing and flute grinding of tungsten carbide end mills, drill points, and rotary tools.
The electroplated bond delivers sharp, aggressive cutting action with no dressing required. The bowl geometry provides clearance for adjacent flutes during grinding, making it well-suited for dedicated knife grinders and CNC tool grinding machines.
The ED-1A1 is a 1A1 straight-profile electroplated diamond grinding wheel designed for high-precision grinding of tungsten carbide, tool steel, and ceramic materials.
The electroplated bond delivers aggressive, consistent stock removal with minimal dressing, making it well-suited for knife grinders, bench grinders, and CNC tool grinding applications requiring sharp, stable cutting action.
The 11A2 flaring cup wheel features an angled rim that provides natural clearance during grinding, eliminating interference with adjacent tool geometry.
Designed for precision flute, relief, and rake face grinding on rotary cutting tools, it is the standard form factor used on 5-axis CNC tool grinders including ANCA, Walter, and Rollomatic machines.
Metal bond construction ensures consistent profile retention across high-volume production runs.
The 6A2 straight cup wheel features a flat annular grinding face, making it ideal for face contact and OD grinding applications.
Its rigid metal bond matrix delivers exceptional wheel life and profile retention, particularly when working with superhard materials such as PCD, PCBN, and tungsten carbide.
Suitable for use on manual and CNC tool & cutter grinders.
The 6A2 is a bowl-profile CBN grinding wheel designed for precision grinding of high-speed steel (HSS), tool steel, and hardened ferrous alloys.
Available in resin bond (RC-6A2) for smooth finish and vibration-damping performance, and vitrified bond (VC-6A2) for free-cutting action, easy dressing, and superior form retention.
The bowl geometry provides clearance for adjacent features during grinding, making it well-suited for CNC tool grinders and surface grinding applications.
Resin-bonded diamond grinding disc for face grinding of tungsten carbide, hardened steel, ceramics, aluminum oxide, and composite materials on tool grinding machines. Full abrasive ring face with high-strength alloy hub body. Custom OD, ring width, thickness, bore, and grit accepted. Standard sizes in stock.
Resin-bonded diamond grinding wheel for surface grinding, tool grooving, flute grinding, and PDC drill bit reconditioning of tungsten carbide cutting tools, HSS tooling, ceramics, and glass. Suitable for CNC tool grinding machines including ANCA, Walter, and Rollomatic. Full custom spec available — OD, bore, body height, grit, and bond hardness per drawing.
The 11V9 resin bond diamond grinding wheel features an angled bowl profile with abrasive on the inner conical face, making it the standard choice for gashing and flute grinding on carbide end mills, drills, and other rotary cutting tools.
The tapered geometry provides natural clearance relief during grinding, eliminating secondary interference with adjacent flute geometry.
Compatible with 5-axis CNC tool grinders including ANCA, Walter, Rollomatic, and Vollmer machines. Resin bond delivers smooth surface finish and self-sharpening action suited for precision tool room applications.
Vitrified bond CBN (Cubic Boron Nitride) grinding tools engineered for precision grinding of hardened steel, tool steel, cast iron, and quenched carbon steel. The ceramic bond structure provides excellent form-holding, thermal stability, and consistent stock removal across a wide range of grinding applications.
This 1A1 vitrified bond CBN grinding wheel is engineered for high-precision OD grinding of crankshaft journals, camshaft lobes, and other hardened steel engine components.
The vitrified bond matrix provides superior form retention, excellent thermal stability, and high porosity for effective coolant penetration — critical requirements in automotive and heavy equipment powertrain manufacturing.
Dimensions, grit, and rpm configurations are fully customizable to match specific machine tool and workpiece requirements.
The 11V9 resin bond diamond grinding wheel features an angled bowl profile with abrasive on the inner conical face, making it the standard choice for gashing and flute grinding on carbide end mills, drills, and other rotary cutting tools.
The tapered geometry provides natural clearance relief during grinding, eliminating secondary interference with adjacent flute geometry.
Compatible with 5-axis CNC tool grinders including ANCA, Walter, Rollomatic, and Vollmer machines. Resin bond delivers smooth surface finish and self-sharpening action suited for precision tool room applications.
The VD-11A2 is an 11A2 bowl-profile vitrified bond diamond grinding wheel designed for precision grinding of PCD, PCBN, ceramic, and tungsten carbide cutting tools.
The bowl geometry with 45° inner face provides clearance for adjacent tool features during grinding, making it particularly well-suited for PCD insert edge preparation, PCBN tool sharpening, and CNC tool grinder applications. The vitrified bond delivers free-cutting action, excellent form retention, and easy dressing.
The VD-1A1 is a 1A1 straight-profile vitrified bond diamond grinding wheel designed for precision grinding of tungsten carbide, ceramic, and hard alloy workpieces.
The vitrified bond delivers superior form retention, free-cutting action, and easy dressing, making it well-suited for surface grinding, OD grinding, and CNC tool grinding applications requiring tight tolerances and consistent wheel geometry over long production runs.
The VD-6A2 is a 6A2 cup-profile vitrified bond diamond grinding wheel designed for precision grinding of PCD (polycrystalline diamond), PCBN, tungsten carbide, and ceramic cutting tools.
The vitrified bond delivers free-cutting action, excellent form retention, and easy dressing, making it well-suited for tool room applications including PCD turning inserts, router bits, PCB drill bits, and spiral milling cutters.
The VDI-1A1 is a 1A1 straight-profile vitrified bond diamond grinding wheel designed for precision internal diameter (ID) grinding of tungsten carbide, ceramic, and hard alloy bores.
The vitrified bond delivers free-cutting action, excellent form retention, and easy dressing, making it well-suited for internal cylindrical grinding of bearing races, mold cavities, hydraulic valve bores, nozzle IDs, and other precision internal features. Available in diameters from 3/8″ (10mm) to 3-1/8″ (80mm) to accommodate a wide range of bore sizes.
These solid vitrified CBN abrasive rings are designed for internal grinding of hardened steel, high-speed steel, tool steel, and die steel components.
The all-CBN construction with no metallic core allows the ring to be bonded or pressed directly onto a grinding spindle or mandrel, making it well suited for small-bore internal grinding operations where dimensional precision and surface finish are critical.
Vitrified bond offers excellent form retention, free-cutting action, and compatibility with water-soluble coolants.
Vitrified-resin hybrid bond diamond grinding wheels with nickel-coated abrasive and steel core body, designed for high-efficiency fluting and gashing of carbide cutting tools on CNC tool grinding machines.
The hybrid bond combines the form retention of vitrified bond with the surface finish characteristics of resin bond, making these wheels well suited for demanding batch fluting operations.
Compatible with ANCA, Walter, Rollomatic, Ewag, and other universal CNC cutter grinders.
